i-tec USB-C HDMI Dual DP Docking Station with Power Delivery 100 W

A high-performance USB-C office dock that supports up to 3x external 4K monitors. The dock is compatible with any laptop equipped with a USB-C, USB4 or Thunderbolt 3/4 port. Of course, it supports charging of your laptop or tablet, up to 100 W.The integrated latest DP 1.4 DSC protocol also supports 5K/60 Hz resolution, which can be appreciated by professional graphic designers, data analysts, film editors or high-definition video lovers.The dock can be purchased in two variants:

• 1. without the included USB-C charging adapter (product code C31TRIPLE4KDOCKPDPRO)
• 2. with the included 100W adapter (product code C31TRI4KDPDPRO100/UK)

Note: macOS operating system does not support Multi Stream Transport (MST) video transmission technology, which means that if connected to macOS, the same image will be projected on both connected monitors.

• Connect up to three external 4K/30Hz monitors
• Refresh rate up to 360Hz (when connected to a single 1080p monitor)
• Power delivery: up to 100W
• 1x HDMI, 2x DisplayPort++
• 3x USB 3.1, 1x USB-C 3.2 Gen2 (10 Gbps) and 2x USB 2.0 allow you to easily connect your USB devices and peripherals. Gigabit Ethernet RJ-45 provides a reliable, robust and high-speed
• Internet connection with 10/100/1000 Mbps support
• Combination audio and microphone jack on the front panel
• Kensington lock provides anti-theft protection, especially in shared office environments or public areas
• Docking station power switch allows for maximum power savings
• Docking station supports a VESA mount for smart vertical installation behind a VESA-enabled monitor
• Supports Windows 10, macOS, Android, iPadOS, ChromeOS and Linux

The dock can be used without a power adapter connected. In this case, the video outputs, LAN (RJ-45), audio/mic and both USB 2.0 ports will always be functional. However, the USB 3.0 ports and the USB-C data port may not work when connecting devices with higher power requirements (e.g. SSDs, especially NVMe drives). In this case, the docking station may shut down. We recommend using the docking station with a power adapter connected to ensure that all ports are used and that maximum data transfer speeds are achieved.Note: If connected to an Android device, the dock will only work with the power adapter connected. The adapter is not included.

• Compatible with USB-C, USB4 and Thunderbolt laptops & tablets. (The host device must support DisplayPort Alt mode).
• 2x DisplayPort++ and 1x HDMI supporting up to three 4K or a single 5K/60Hz display (depending on notebook performance). macOS supports a single extended display only.
• 6x USB-ports (5x USB-A, 1x USB-C) make it easy to connect multiple USB devices and peripherals.
• Provides up to 100W Power Delivery for compatible USB-C, USB4 and Thunderbolt laptops & tablets. The host device must support USB-C Power Delivery.
• GLAN Ethernet supports network speeds of 10/100/1000 Mbps speeds, providing a robust and high-speed internet connection.
• Combo 3.5 mm audio input/output jack for easy connection to headset or speakers.
• VESA bracket available to help keep your desk tidy and free from cables, plus K-lock slot for added security.
• Power-saving On/Off switch to reduce energy consumption when the docking station is not in use.
• Note: Power supply not included.

• 1x integrated USB-C cable for connection to the device (100 cm)
• Docking station technology: USB-C (MST)
• Power Delivery: up to 100 W
  • Internal power consumption: 5-10W (more info here)
• Video Ports: 2x DisplayPort (supports DP++), 1x HDMI

• Resolution:
• Host device with DisplayPort 1.2 support:
  • 1 monitor - 1x HDMI or DP- up to 4K/30Hz
  • 1 monitor - 1x HDMI or DP - up to 1080p/120Hz
  • 2 monitors - 1x DP + 1x HDMI - up to 2x 1080p/60Hz*
  • 2 monitors - 2x DP - up to 2x 1080p/60Hz*
  • 3 monitors - 1x HDMI + 1x DP + 1x DP - up to 1x 1080p/60Hz + up to 2x 720p/60Hz*
• Host device with DisplayPort 1.4 support:
  • 1 monitor - 1x HDMI - up to 4K/60Hz
  • 1 monitor - 1x DP - up to 4K/60Hz
  • 2 monitors - 1x DP + 1x HDMI - up to 2x 1440p/60Hz*
  • 2 monitors - 1x DP + 1x HDMI - up to 2x 4K/30Hz*
  • 2 monitors - 2x DP - up to 2x 4K/30Hz*
  • 3 monitors - 1x HDMI + 1x DP + 1x DP - up to 3x 1080p/60Hz*
• Host device with DisplayPort 1.4 with DSC support:
  • 1 monitor - 1x HDMI - up to 4K/60Hz
  • 1 monitor - 1x DP - up to 5K/60Hz
  • 1 monitor - 1x HDMI - up to 1440p/144Hz or 1080p/240Hz
  • 1 monitor - 1x DP - up to 4K/144Hz or 1440p/240Hz or 1080p/360Hz
  • 2 monitors - 1x DP + 1x HDMI - up to 2x 4K/60Hz*
  • 2 monitors - 1x DP + 1x HDMI or DP - up to 2x 1440p/144Hz*
  • 3 monitors - 1x HDMI + 1x DP + 1x DP - up to 3x 4K/30Hz*

• 1x USB-C 3.2 Gen. 2 port (10 Gbps)
• 1x USB-C 3.2 port Gen. 2 (10 Gbps) + PD (Power delivery)
• 3x USB-A 3.2 port Gen. 1 port (5 Gbps)
• 2x USB 2.0 port
• 1x Ethernet GLAN RJ-45 port (Realtek 8153B)
• 1x 3.5 mm Combo Audio port
• LED indication
• ON/OFF switch to turn the docking station on and off
• MAC Address cloning: Yes (using i-tec Docker Pro software)
• WOL: S1, S2, S3
• Support for Kensington lock
• OS: Windows 11, Windows 10, macOS*, iPadOS**, Android**, Chrome OS and Linux with latest updates
• Product dimensions: 113 x 113 x 31.2 mm
• Product weight: 340 g
• Package dimensions: 250 x 242 x 50 mm

 Hardware Requirements:

• Device with a free USB-C, USB4 or Thunderbolt™ 3/4 port

Power Delivery Requirements:

• Device with a free USB-C, USB4 or Thunderbolt™ 3/4 port with Power Delivery support

Video Output Requirements:

• Device with a free USB-C or USB4 port with DisplayPort Alternate Mode support or a Thunderbolt™ 3/4 port

Operating System:

• Windows 10 / 11, macOS*, iPadOS**, Android**, Chrome OS and Linux with latest updates

PACKAGE CONTENTS

• Product
• Manual
