SWIT PL-E90L 90W Bi-color Panel LED Light

SWIT PL-E90L 90W Bi-color Panel LED Light

• 480pcs edge mounted SMD-LEDs
• 0-100% flick-free dimming
• LCD display color, dimmer and battery info
• DC 11-36V wide input voltage
• Power by V-mount / Gold mount battery

90W Long Ratio LED Panel
PL-E90L is a 0,5x3 feet size long aspect ratio light for soft verical lighting of people. The PL-E family slim size is portable for interview kit application

21mm Slim Size
Side Mounted SMD-LED
PL-E90L has SMD-LEDs side mounted on the inner edge of the frame, and with SWIT innovative laser dots 90° reflection board, the light outputs high efficiant bright, soft and even beam to wrap around objects.
The side mounted LEDs greatly reduce the light thickness. It’ s only 21mm, slim and portable for field application.

Control Panel
The rear control supports DMX512 in and out, USB power out for wireless DMX adaptor, DC 11-36V wide input. The LCD screen displays dimmer, color temperatue, DMX adress and power status.

Rotable Lighting Angle
PL-E90L provides a light stand connector with 300 degrees rotable and 180 degrees tiltable.

For more information, see the downloadable pdf under the product media tab below.

Included in the box
1x PL-E90L lights with barndoor
1x Light stand connector
1x AC-DC adaptor
1x Carrying bag

Specifications
LED 480pcs SMD LEDs
Illuminance 2200Lux @ 1m
Beam angle 70°
Color Temperature 2700K～6500K
CRI 98
TLCI 99
Power Approx. 90W
Working voltage DC11V～36V
Dimension 839×163×21mm
Lighting area 781×104mm
Weight Net 4.75kg; Single light package 8.4kg
